Description

The Truma Aventa Compact Air Con is a high-performance roof-mounted air conditioner designed for caravans and motorhomes where efficient cooling and low roof height are essential.

Finished in cream, it delivers rapid temperature reduction and is proven to cool faster than comparable roof-mounted units. Operation is straightforward using the included remote control, with optional smartphone control available when paired with the Truma iNet Box. With a powerful 1700W cooling output and airflow of up to 370 m³/h, it maintains comfort across a wide temperature range from +16 °C to +40 °C.

The compact air distributor does not require filters, reducing maintenance compared to larger comfort models, while remaining compatible with standard roof cut-outs.

Key Features

• Cools faster than any other roof-mounted air conditioner
• Convenient adjustment using air control
• Control air conditioner and ACC using the app (optional with Truma iNet box)

Product Specification

• Power supply: 230V
• Power consumption. Cooling: 2.8A
• Start-up current: 20A (150 ms)
• Cooling power: 1700 W
• Volumetric air flow: max. 370 m³/h
• Deployment range: +16 °C to +40 °C
• Maximum incline during operation: 8%
• Weight (without installation material): approx. 27.5 kg
• Outer dimensions (L x W x H): 785 x 560 x 265 mm
• Inner dimensions (L x W x H): 556 x 496 x 46 mm (Air distributor small)
• Roof cut-out (L x W): 380 x 350 mm / 400 x 400 mm
• Power consumption. Heating: N/A
• Heating power: N/A

Instructions Manual

You can find a generic installation manual here. Please note that in this manual, it states ‘do not use without filters’, however this doesn’t apply to this particular aircon unit.
