Thetford slide ez valve repair kit

Description

Slide ez valve repair kit for Thetford Slide Ez valve 8706 08706 35770 2H ABS SEV SALES PKG
This kit contains all the seals required to repair any all plastic Thetford slide valve termination valve.

Includes:

• Large flat perimeter gasket that is sandwiched between two plastic layers of valve
• Gasket that seals against the blade inside the valve
• O-ring for valves with O-ring connections on the outlet side, like the 8706 8707
• Gasket for “flat top” valves that bolt directly to a Thetford valve mounting flange
• Mounting bolts
• Floor Flange seal

This is Thetford part 35776 (was 9872 09872 1634).
If you have a stainless steel top plate Thetford valve, this kit will not work. You would need Repair Kit 03827 which is discontinued.

This can also be used on Electra Magic Slide EZ valves of Electra Magic Model 80 recirculating toilets.

Mounting holes are 4-1/4″ on center. Approximately 6″ across mounting holes if measured diagonally.
